ELDOM vertical water heater with 1 coil (left-side), 150
left-hand coil, enameled water tank, 3 kW
NEWProductID WVF15046FML
Compare
Download brochureThe unit is available in two versions—with the coil connections located on either the left or the right side (models ***L and ***R).
Equipped with a single coil, it is suitable for use with a heat pump, thanks to the large surface area of the coil, which spans the entire volume of the water heater.
• ENERGY-SAVING:
- Sensor sleeves for the heat exchanger—designed for the installation of thermal sensors to ensure precise control of the heating system and its economical operation;
- Features HFO Closed-Cell thermal insulation with a fine, closed-cell structure. This is an eco-friendly, next-generation polyurethane system offering high energy efficiency. The insulation, exceeding 33 mm in thickness, ensures minimal heat loss and significant energy savings.
New, improved design with a matte white finish:
• Twin LED visual indicator:
- Red light – heating mode;
- White light – target temperature reached.
• Combined control knob for switching the unit on and adjusting the temperature;
• ECO mode: thermostat setting at 60°C, the most economical operating mode for the water heater.
• LONG SERVICE LIFE:
- SHIELD technology – the water tank is protected by a zirconium-based enamel, formulated specifically for superior wear resistance;
- A dual magnesium anode system, providing optimal corrosion protection throughout the entire internal volume. • SECURE: features a unique six-level protection system:
- a special elliptical flange – a patented design ensuring maximum safety in the event of excess pressure;
- an external capillary thermostat – allows for easy adjustment of the desired water heating temperature;
- a capillary thermal cut-out – reliably protects the appliance against overheating;
- a combined metal valve with dual protective functions – acting as both a non-return and a safety valve;
- freeze protection – the thermostat automatically maintains the water temperature above 5°C;
- high-grade moisture protection – IP24.
• Tubular electric heating element, specifically designed for this model and manufactured by ELDOMINVEST using state-of-the-art technology.
• Antibacterial protection: setting the thermostat to the maximum level eliminates all viruses and bacteria.
• Temperature indicator – lets you know the current temperature of the water in your water heater at all times.
• Illuminated switch.
| Installation: | Vertical |
| Capacity range: | 150 |
| Water tank: | Enameled |
| Energy efficiency class: | C |
| Weight [kg]: | 60 |
| Number of coils: | 1 |
| Dimensions ØxH [mm]: | 462 х 1420 |
| Height x Width х Depth [mm]: | 1420 x 462 x 484 |
| Nominal power (kW): | 3 |
| Nominal volume [l]: | |
| Colors: | |
| Weight: | 60.0 kg. |
